114 Removing adapter cards and riser card
3. Disconnect the power cable from the riser card and
remove the riser card screw. Then remove the riser
card.
note:
To reinstall the adapter cards and the riser card,
reverse the removal procedure.
(Front)
(Top)
(Back)
(Bottom)
Riser Card
Connector
Riser
Card
2
1
System Board
bi2gntce.bk : bi2gusy2.doc Page 114 Saturday, June 3, 1995 6:54 AM
