5 - ADJUSTMENTS AND SETTING-UP BOSS 332/545/552 HD
EN
5 - Pag. 23 / 34
Open the guard and proceed as follows:
• Loose the screw, adjust the flag position and
tighten the screw.
• Close the upper guide channels.
• Move the bar pusher forwards and backwards
in the flag area to make sure that its stroke is
not hindered.
