IEMCA BOSS 545 E - 2.7 ACCESSORIES - FOREWORD; 2.7.1 Bush holder device - Description

2 - TECHNICAL INFORMATION BOSS 332/545/552 HD
EN
2 - Pag. 27 / 32
2.7.2 Axial displacement device - Description
It allows the bar feeder to be moved away from
the lathe to allow maintenance, cleaning or any
other servicing of the lathe.
Overall dimensions
Model Version A (mm) B (mm)
21 1880 600
32 3170 900
37
3770 900
BOSS 332 – BOSS 332r
BOSS 545 - BOSS 545r
BOSS 552 HD- BOSS 552r-HD
44
4370 900
