IEMCA BOSS 545 E - 4.5.5 Levelling and alignment

EN
4 - HANDLING AND INSTALLATION BOSS 332/545/552 HD
4 - Pag. 20 / 32
• Position the remaining eight plates under the
axial displacement sliding frame in the positions
indicated in the figure, then tighten the cone
end grub screws "B".
