EN
10 - GUIDE CHANNELS - BAR PUSHER - REVOLVING TIPS BOSS 332/545/552 HD
10 - Pag. 2 / 16
10.1 TABLE
The choice of the guide channels and the bar pusher must be made according to the diameter
of the bar to be machined. The bar feeder is usually supplied with a bar pusher whose diameter
is equal to the maximum bar passage of the lathe. Sometimes, in order to ensure the best
working conditions, it may be necessary to use a bar pusher with a smaller diameter.
A Guide channels
B Bar pusher
C Revolving tip
D Collet
E Bar
