IEMCA BOSS 545 E - 10.4 Revolving tips ØGR 12÷27 - Table

EN
10 - GUIDE CHANNELS - BAR PUSHER - REVOLVING TIPS BOSS 332/545/552 HD
10 - Pag. 12 / 16
øGR
(mm)
Revolving tip code
øF
(mm)
øB
(mm)
GP
(mm)
G1
(mm)
C
(mm)
A1
(mm)
øSP
(mm)
A2
(mm)
øSP1
(mm)
10 D71151011 7 10.5 143 30 8 6 3 18 4
12 D71151211 8 12.5 143 30 8 6 3 18 4
15 D71151511 11 15.5 160 35 12 6 3 18.5 6
16 D71151611 11 16.5 160 35 12 6 3 18.5 6
18 D71151811 11 18.5 160 35 12 6 4 18.5 6
19 D71151911 11 19.5 160 35 12 6 4 18.5 6
20 D71152011 14 20.5 172.5 35 14 6 4 37.5 8
1
1
21 D71152111 14 21.5 172.5 35 14 6 4 37.5 8
6
23 D71152311 14 23.5 172.5 35 14 6 4 37.5 8
25 D71152511 20 25.5 172.5 35 17 6 5 37.5 8
27 D71152711 20 27.5 172.5 35 17 6 5 37.5 8
29 D71152911 20 29.5 172.5 35 17 6 5 37.5 8
