10 - GUIDE CHANNELS - BAR PUSHER - REVOLVING TIPS BOSS 332/545/552 HD
EN
10 - Pag. 11 / 16
10.4 Revolving tips ØGR 12÷27 - Table
• For collets with quick coupling pin
A Collet
B See file
C See file - 001
then - 602P
D Ejector
E Pipe collet
F Revolving tip
