2.8.2 Telescopic front nose - Description
It is used to optimize bar guiding between the
bush holder device and the lathe spindle.
Maximum stroke and overall dimension
Model
Maximum stroke
A (mm)
Overall dimensions
B (mm)
200 270
210 270
230 300
280 430
BOSS 332
BOSS 545
BOSS 552-HD
330 480
