IEMCA BOSS 545 E - 11.14 BORING COLLETS FOR BARS 601 P; 11.15 BORING COLLETS FOR SQUARE AND HEXAGONAL BARS - Table

11 - COLLETS BOSS 332/545/552 HD
EN
11 - Pag. 19 / 34
S square bars (S=E/1,414) S hexagonal bars (S=E/1,154)
MIN MAX MIN MAX
External diameter
(mm)
øD
Diameter (mm)
øF
3 3 3 4 7,5 M5x0,5
4 6 5 7 12 Ø8 G6
6 10 6 13 18 Ø11 G6
7 12 * 5/16” 15 21 Ø14 G6
10 12 8,5 19 25 Ø20 G6
13 15 / / 25 M5x0,5
16 17 / / 29 Ø8 G6
/ / 17 * 7/8” 29 Ø20 G6
18 20 / / 32 Ø11 G6
/ / 20 25 32 Ø20 G6
21 * 1” 1/8 36 Ø20 G6
21 23 / / 36 Ø14 G6
/ / * 1” 1/16 * 1” 1/16 40 Ø20 G6
WARNING: Values indicated with * are expressed in inches.
