IEMCA BOSS 545 E - 9.3 REPLACEMENT OF THE GUIDE CHANNELS WITH INSERTS WITH POLYURETHANE GUIDE CHANNELS

EN
9 - PART REPLACEMENT BOSS 332/545/552 HD
9 - Pag. 4 / 6
• Assemble the polyurethane guide channels as
shown in the figure.
IMPORTANT:
Do not re-use the fastening screws of the
guide channels with inserts.
WARNING:
The polyurethane guide channels can be
fastened also by using screws: in this
case, use the dedicated screw set
supplied by IEMCA.
