IEMCA BOSS 545 E - 2.5 VERSION DESCRIPTION

2 - TECHNICAL INFORMATION BOSS 332/545/552 HD
EN
2 - Pag. 11 / 32
2.6 TECHNICAL DATA
(*) Without axial displacement device, the minimum value can be decreased to 850 mm.
Overall dimensions
Model Version A (mm) B (mm) C (mm)
21 2603 / /
32 3802 1220 /
37 4342 1760 /
44 5002 2420 /
BOSS 332 – BOSS 332r
BOSS 545 - BOSS 545r
BOSS 552 - BOSS 552r
64 6382 1979 1520
