EN
2 - TECHNICAL INFORMATION BOSS 332/545/552 HD
2 - Pag. 30 / 32
2.9 DEVICES FOR CAM LATHES - FOREWORD
This bar feeder has been designed and manufactured to be coupled to cam lathes too. To do
this, special devices are available which are listed and then described below.
2.9.1 Headstock return device - Description
It is needed when the lathe headstock return
spring size hinders bar feeder installation.
The original lathe spring "A" is then installed
inside the bar feeder.
2.9.2 Cam box - Description
Used to synchronize the bar feeder and cam lathe
movements. The cams located in the box "A" are
connected to the lathe camshaft "B".
