4 - HANDLING AND INSTALLATION BOSS 332/545/552 HD
EN
4 - Pag. 21 / 32
4.5.6 Bar feeder fastening
Ground fastening
• Drill the floor and fix the (axial displacement)
frame with expansion plugs.
• Check the levelling and alignment.
• Tighten nuts "A" and screws "B".
• Check the levelling and alignment once more.
• Remove all the equipment used for the levelling
and alignment phases and restore the initial bar
feeder conditions.
Fastening to the lathe
See the "BAR FEEDER FASTENING" section, CH. 4.
4.5.7 Telescopic front nose - Installation
See the "TELESCOPIC FRONT NOSE - INSTALLATION" section, CH. 4.
