EN
2 - TECHNICAL INFORMATION BOSS 332/545/552 HD
2 - Pag. 6 / 32
When the first feeding carriage "M" completes its
stroke, the required space has been created for bar
pusher insertion.
The first feeding carriage performs the return
stroke.
Upper guide channels "H" are closed; bar pusher
"A" is placed along the spindle axis.
The clamps "D" close, the bar pusher "A" moves
forwards; the bar "G" is inserted into the bar
pusher collet.
Bar pusher "A" and bar "G" perform their facing
stroke. A new automatic working cycle is started.
