10 | Routine Operation INFICON
262 / 319 074-594-P1H Micro GC Fusion Operating Man-
ual
11
Remove the retaining screws:
ð For modules C/D, remove the retaining screw holding the JP-100 in place
with the 2.5 mm ball point hex driver.
ð For modules A/B, remove the retaining screw holding the JP-100 in place with
the 2.5 mm ball point hex wrench.
12
Slide the JP-100 up and out of the instrument.
13
See GC Module Removal Procedure for 4-Module System [}273] to continue
the module removal process.
