Ingenico Move 5000 - Bluetooth Base

Page 18
Move/
5000
User Guide
Copyright© 2019 Ingenico
Bluetooth Base: Used for charging the terminal battery and has ports to
allow terminals to communicate with hosts over Ethernet.
It is needed if you want to communicate with the base via BT and then use
the LAN to connect to remote host.
You should set up your base unit in a convenient location close to a power source
and network point.
To open the base unit cover, located on the bottom of the base unit, you must
unclip an access clip and lift the cover from the base unit. To replace the cover
reverse these instructions being sure to engage all the retaining pins before the
access clips.
Terminal
guides
Terminal
charging points
Power
socket
Ethernet Port USB Ports
