Storage System Features
4 Intel
®
Entry Storage System SS4000-E User Guide
Table 1. Component Definitions
Call out Component Definition
A NIC 1 Activity LED Blinking GREEN indicates Ethernet activity.
B NIC 1 Link LED Continuous GREEN indicates an active Ethernet connection.
Off indicates no active Ethernet connection.
C NIC 2 Link LED Blinking GREEN indicates Ethernet activity.
D NIC 2 Activity LED Continuous GREEN indicates an active Ethernet connection.
Off indicates no active Ethernet connection.
E Drive Carrier - 1 3.5-in SATA drive carrier
F Drive Carrier - 2 3.5-in SATA drive carrier
G Hard Disk Activity
LED Light Pipe
Continuous GREEN indicates the drive is available.
Blinking GREEN indicates drive activity.
Continuous YELLOW indicates a fault condition, possibly
requiring the hard disk to be replaced.
Blinking YELLOW indicates the drive is currently rebuilding RAID.
H Drive Carrier - 3 3.5-in SATA drive carrier
I Drive Carrier - 4 3.5-in SATA drive carrier
J Global Disk Status
LED
Continuous GREEN indicates hard disk health is good (1-4 hard
disks).
Continuous YELLOW indicates a critical or non-recoverable
condition exists. It also indicates the hard drives are not
configured when initially setting up the system.
Blinking YELLOW indicates one or more hard disks are
experiencing a fault condition or a RAID is being rebuilt.
K System Status LED Continuous GREEN indicates the system is running and
operating normally.
Blinking GREEN indicates the system is in process of powering
up or shutting down.
Continuous YELLOW indicates a fault is present, either a critical
or non-recoverable condition.
L Power LED Continuous GREEN indicates the system has power applied to it.
No light indicates the system does not have power applied to it.
M Power Button Toggles the system power on/off.
