Getting Started
Intel
®
Entry Storage System SS4000-E User Guide 13
7. Label the hard disk with the appropriate label. Starting with the uppermost drive, label
the hard disks, 1 to 4, in the order shown in the following figure.
Note: The order of drive carriers is critical when replacing hard disks or
performing maintenance. A hard disk plugged into an incorrect slot once set
up for RAID can result in data loss or an improperly functioning storage
system.
Figure 8. Applying Label to Hard Disk
Figure 9. Order of Drive Carriers
AF000241
HD 1
TP02348
1
2
3
4
1
2
4
3
2
1
