Intel Stratix 10 Configuration User Guide

For example, if you are using dual P30 or P33, the programmer window shows a
dual P30 or P33 chain in your setup. Alternatively, you can add the flash memory
device to the programmer manually. Right-click the CPLD .pof and click Attach
Flash Device. In the Select Flash Device dialog box, select the device of your
choice.
6. Right-click the necessary flash memory device density and click Change File.
Note: You must select the density that is equivalent to the sum of the density of
two CFI flash memory devices. For example, if you require two 512-Mb CFI
flash memory devices, then select CFI 1 Gbit.
7.
Select the .pof generated for the flash memory device. The .pof for the flash
memory device is attached to the .pof of the CPLD.
8.
Check the boxes under the Program/Configure column for the added .pof and
click Start to program the flash memory devices.
Note: The Programmer allows you to program, verify, erase, blank-check, or
examine the configuration data page, the user data page, and the option
bits sector separately, provided the CPLD contains the PFL II IP core. The
programmer erases the flash memory device if you select the .pof of the
flash memory device before programming. To prevent the Programmer from
erasing other sectors in the flash memory device, select only the
pages, .hex data, and option bits.
3.1.6.2.5. Defining New CFI Flash Memory Device
The PFL II IP core supports Intel-compatible and AMD-compatible flash memory
devices. In addition to the supported flash memory devices, you can define the new
Intel- or AMD-compatible CFI flash memory device in the PFL II-supported flash
database using the Define new CFI flash memory device feature.
To add a new CFI flash memory device to the database or update a CFI flash memory
in the database, follow these steps:
1. In the Programmer window, on the Edit menu, select Define New CFI Flash
Device. The Define CFI Flash Device window appears. The following table lists
the three functions available in the Define CFI Flash Device window.
Table 16. Functions of the Define CFI Flash Device Feature
Function Description
New Add new Intel- or AMD-compatible CFI flash memory device into the PFL II-supported flash database.
Edit Edit the parameters of the newly added Intel- or AMD-compatible CFI flash memory device in the PFL
II-supported flash database.
Remove Remove the newly added Intel- or AMD-compatible CFI flash memory device from the PFL II-
supported flash database.
2. To add a new CFI flash memory device or edit the parameters of the newly added
CFI flash memory device, select New or Edit. The New CFI Flash Device dialog
box appears.
3. In the New CFI Flash Device dialog box, specify or update the parameters of the
new flash memory device. You can obtain the values for these parameters from
the datasheet of the flash memory device manufacturer.
3. Intel Stratix 10 Configuration Schemes
UG-S10CONFIG | 2018.11.02
Send Feedback
Intel Stratix 10 Configuration User Guide
45
