112 EasyCoder PX4i and PX6i Service Manual

Chapter 9 — Liner Takeup Kit

EasyCoder PX6i

Pulley

Bearing

Flange

Spring

Shaft

Brake sleeve

Bearing

Bobbin

#T10 Torx

screws (x2)

Bobbin

plate

Bobbin gable

Bearing

Snap ring

Bearing

Snap ring

Flange

Spring brake assy.
