Intermec EasyCoder PX6i Service Manual

6 EasyCoder PX4i and PX6i Service Manual
Chapter 1 — Models and Options
Interfaces
The printers are as standard provided with one serial RS-232 port, one
serial USB port, and one wand interface. The wand interface is not sup-
ported by IPL. In addition, one EasyLAN interface and one or two extra
interface boards can be fi tted, see Chapter 14. IPL does only support one
EasyLAN interface and one parallel interface board.
Serial Port (RS-232)
USB Port
Provision for
one or two interface
boards (only the left
slot used with IPL)
Provision for Ether-
net connector
Wand interface
(not used with IPL)
Provision for Easy-
LAN antenna

Intermec EasyCoder PX6i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Product color	Silver
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	170 mm
Maximum label length	4 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	335 mm
Weight	14800 g
