EasyCoder PX4i and PX6i Service Manual 165
16
Interfaces
This chapter describes the various communication interfaces for the Easy-
Coder PX4i and PX6i printers. However, some interfaces are not sup-
ported by the Intermec Programming Language (IPL) even though the
connectors are present.
The chapter describes three categories:
• Standard built-in interfaces
RS-232 interface
USB interface
Bar code wand interface (Fingerprint only)
• Optional interface boards
Serial/Industrial interface board (Fingerprint only)
Double Serial interface board (Fingerprint only)
IEEE 1284 Parallel interface board
• EasyLAN interface boards
EasyLAN Ethernet interface
EasyLAN Wireless interface
The EasyCoder PX4i and PX6i can—in addition to the standard built-in
interfaces—also be fi tted with one or two optional interface boards and
one EasyLAN interface board.
Note: Device designations, such as "uart1:", "usb1:", or "net1:", only
apply to Fingerprint, not to IPL.

Intermec EasyCoder PX6i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Product color	Silver
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	170 mm
Maximum label length	4 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	335 mm
Weight	14800 g
