206 EasyCoder PX4i and PX6i Service Manual

Chapter 16 — Interfaces

Antenna

EasyLAN

adapter board

Light guideCable clips

#T20 Torx screw

and spacer

Antenna cable

Cable tie

Antenna

(packed separately when the EasyLAN Wireless

interface is factory-installed)
