EasyCoder PX4i and PX6i Service Manual 31

Chapter 4 — Chassis

Bottom plate

Center section

Rubber foot (x4)

Rear plate

Hinges

(front door

or cutter)

Hinges

(right-hand door)

EasyCoder PX6i

The main differences between the chassis of EasyCoder PX4i and PX6i are

the widths of the bottom plate and the rear plate.
