44 EasyCoder PX4i and PX6i Service Manual
Chapter 5 — Media Supply
Media Load
Load the media according to the illustrations below.
The external supply should be protected from dust, sand, grit and other
particles that may damage the printhead or impair the printout qual-
ity.
Note: If the printer is to be permanently used with an external media
supply only, the entire internal media supply unit could easily be removed
(see Chapter 5.1).
