48 EasyCoder PX4i and PX6i Service Manual

Chapter 6 — Label Slack Absorber

#T20 Torx screws (2x)

Flange

#T10 Torx screw

Torsion spring

Grip (green)

Edge guide

(green)

EasyCoder PX6i

#T10 Torx screw

Spacer
