66 EasyCoder PX4i and PX6i Service Manual
Chapter 8 — Print Unit
The parts of the print mechanism fi tted inside the electronics compart-
ment in an EasyCoder PX4i printer are illustrated below.
Stepper motor
(platen roller & ribbon
rewind unit)
Pulley & belt
(liner drive
roller)
Pulley & belt
(platen roller)
Stepper motor
(liner takeup)
Driver board
Ribbon
rewind unit
CPU board
Idle roller
