Goodrive300-01A-RT series integrated machine Function description
-47-
Function
code
Name
Description
Default
Modify
BIT13–BIT15: Reserved
P07.06
Selection 2 of
parameters displayed
in running state
0x0000–0xFFFF
BIT0: Analog P1- value (V on)
BIT1–BIT3: Reserved
BIT4: Motor overload percentage (% on)
BIT5: VFD overload percentage (% on)
BIT6: Ramp frequency reference value (Hz
on)
BIT7: Linear speed
BIT8: AC incoming current
BIT9–15: Reserved
0x0000
○
P07.07
Selection of
parameters displayed
in stopping state
0x0000–0xFFFF
BIT0: Set frequency (Hz on, frequency blinks
slowly)
BIT1: Bus voltage (V on)
BIT2: Input terminal state
BIT3: Output terminal state
BIT4: PID reference value (% blinks)
BIT5: PID feedback value (% on)
BIT6: Torque setting value (% on)
BIT7: Analog P1- value (V on)
BIT8–BIT15: Reserved
0x00FF
○
P07.08
Frequency display
coefficient
0.01–10.00
Displayed frequency = Running frequency *
P07.08
1.00
○
P07.09
Rotational speed
display coefficient
0.1–999.9%
Mechanical rotation speed =120 * (Displayed
running frequency) × P07.09/(Number of
motor pole pairs)
100.0%
○
P07.10
Linear speed display
coefficient
0.1–999.9%
Linear speed = (Mechanical rotation speed)
× P07.10
1.0%
○
P07.11
Temperature of rectifier
bridge module
0–100.0℃
●
P07.12
Temperature of inverter
module
0–100.0℃
●
