Chapter2 Status register
You can get the current status of the power supply by reading the status
registers. The power supply records the different status of the instrument
through the four status register group. The four status register groups are:
Questionable Status Register, Operation Status Register, Standard Event
Register and Status Byte Register. Status Byte Register records the
information of the other status register.
The following table describes the status signals.
Bit name
Bit
Decimal value
Definition
Questionable Status Register
OV
0
1
Output is disabled by the over-voltage
protection.
OC
1
2
Output is disabled by the over-current
protection.
OP
2
4
Output is disabled by the over-power
protection.
UV
3
8
Output is disabled by the under-voltage
protection.
OT
4
16
Output is disabled by the
over-temperature protection.
UC
5
32
Output is disabled by the under-current
protection.
SRvs
6
64
Sense malfunction.
LINE
7
128
Off Line.
PS
10
1024
Protect shutdown.
UNR
12
4096
Output is unregulated
WDOG
13
8192
Watchdog protection。
RI
14
16384
Self-locking protection。
Operation Status Register
Cal
1
2
The power supply is under calibration。
List
2
4
The power supply is running the list
program.
WTG
3
8
The power supply is waiting for a
trigger.
CV
4
16
Output is in constant voltage.
CC
5
32
Output is in constant current.
On_Delay
7
128
The power supply is in the output-on
delay.
Off_Delay
8
256
The power supply is in the output-off
delay.
On
9
512
Output is programmed on.
List Pause
12
4196
The list program pauses.
Standard Event Register
OPC
0
1
All commands before and including
*OPC have been executed.
QYE
2
4
The instrument tried to read the output
buffer but it was empty, a new
command line was received before a
previous query has been read, or both
the input and output buffers are full.
