Itotec SC115Z - How to change the knife; How to remove the knife

5
knife lowers to the bottom. Then release
the cutting buttons.
from the leftmost one appears.
Adjust to slow down slowly.
Turn the knife change lever to "CHANGE"
carrier to its original position.
How to change the knife
Select the manual mode.
Press and hold the cutting buttons until the
The knife carrier is stopped when the cutting
Move the backgauge to over 200 mm position.
buttons are released, and the second knife bolt
Use the accessory Allen T wrench to remove
only the scond knifr bolt from the leftmost.
Press the cutting buttons to return the knife
How to remove the knife 1
Remove stacked paper or the like from the surface plate. Otherwise
stacked paper will push out the knife holder or the like during erro
-
neous backgauge advance in knife change work.
Leave
knife change to those who have undergone special training
course and observe instruction given in the instruction manual.
Otherwise injuries will be caused.
Prohibit
approach of athird party near the machine during knife
change or height adjustment work.
Otherwisw injuries will be caused.
To
install or remove the knife, prepare necessary tools in advance
and follow the predetermined procedure and be deliberate.
1 .
Keep the main motor operating.
2 .
3 .
4 .
5 .
2
2
1
4
6 .
５
５
６
While the lever is on the "CHANGE" side,
Operation is prohibited except advance/
retract button.
CAUTION
CAUTION
To work with the knife lowered, stop the
knife with its cutting edge in contact with
the cutting stick.
