The main motor does not start if the clutch key is turned on.
The clutch does not function in the following states even if the clutch key is operated.
② Turn the key on and turn the worm shaft with a wrench to manually move the knife
③ Turn the key on/off to adjust the clutch.
① It is turned off during regular operation.
① For 150 seconds after the power is turned on.
② For 150 seconds during main motor operation after the main motor stop button is
③ For 150 seconds during main motor operation after the clutch key is operated.
How to use the clutch - key
Turning the clutch key on releases the knife brake. Leave the clutch key turned off
unless the manual shaft is turned with a wrench or held.
Otherwise the knife will drop due to ita own weight.
Keep away from parts or terminals other than clutch key.
Otherwise failures will be caused to the machine or injuries will be caused due to
electric shock.
