Itotec SC115Z - How to Make Fine Adjustment of the Knife Height

5
Remove from the knife height adjusting
After adjusrment is finished on the left
window.
and right sides, turn the fixing pin 90
degrees back to the original position.
Pull the fixing pin and turn it 90 degrees.
Using the adjusting handle, adjust the
height.
How to change the knife
How to make fine adjustment of the knife height
1.
2.
3.
4.
Do not lower or raise the knife too much
unnecessarily.
Otherwise the safety bolt will be broken
and/or the macjine will bedamaged.
When turning the knife height adjustment
handle, be careful of the cuttingof the
knife and edge of the main body.
Otherwise injuries will be caused.
To raise the knife, turn the adjusting
handle toward counterclockwise.
To lower the knife tuen toward
clockwise.
Check that the fixing pin fits the hole
when it returns, If the pin does not
enter, move the adjusting handle
slightly to the left or right.
1 1
2
3
4
CAUTION
53
