Install the knife handle.
Pull the knife on the surface plate.
face should face up.
How to change the knife
Place the knife in the storage box on the
Select the manual mode.
Move the backgauge to over 200 mm position.
The cutting edge should face you and the knife
surface plate. Place it with the cutting edge
facing you and with the knife face facing up.
When placing the knife on the surface
plate, do ont allow the cutting edge
protruding from the surface plate.
Otherwise injuries will be caused with
the cutting edge.
How to install the knife 1
2.
3.
When housing or retrieving the knife in/out
of the storage box, use the knife handle
and keep away from the edge.
Otherwise injuries will be caused with the
cutting edge.
4.
When removing or installing the holder or
handle fro /to the knife, be careful of the
cutting edge of the knife.
Otherwise injuries will be caused.
1.
１
3
3
CAUTION
CAUTION
CAUTION
CAUTION
Remove stacked paper or the like from the surface plate. Otherwise
stacked paper will push out the knife holder or the like during erro
-
neous backgauge advance in knife change work.
Leave
knife change to those who have undergone special training
course and observe instruction given in the instruction manual.
Otherwise injuries will be caused.
Prohibit
approach of athird party near the machine during knife
change or height adjustment work. Otherwisw injuries will be caused.
To install or remove the knife, prepare necessary tools in advance
and follow the predetermined procedure and be deliberate
.
