Itotec SC115Z - Left;right adjustment of the backgauge

5
Turn the fixing bolt counterclockwise to loosen it.
counterclockwise by the error to loosen it.
Turn the fixing bolt clockwise to fix it.
Check the result of adjustment.
on both sides.
If the adjustment is insufficient or too much, repeat above .
After adjustment is finished, tighten the lock nuts of thw left/right adjusting screws
maintenance
Loosen the lock nut of the left/right adjusting screw on the left side, and turn it
After loosening the lock nut of the left/right adjusting screw on the right side, turn the
screw clockwise by the extent of loosening in step , to tight it.
If the left side protrudes : adjustong scxrew on left side.
If the right side protrudes : adjusting screw on right side.
If the left side protrudes : adjustong scxrew on right side.
If the right side protrudes : adjusting screw on left side.
Left/right adjustment of the backgauge
1.
2.
3.
Do not put all your weight on the wrench or do not use a pipe to tighten excessively.
Otherwise the backgauge will be broken.
7.
If the left side
protrudes
4.
5.
6.
2 -
5
Adusting screw
(right-side)
Fixing bolt
2
CAUTION
Adusting screw
(left-side)
If the right side
protrudes
76
