Before you begin installing a transceiver in an EX Series switch, ensure that you have
taken the necessary precautions for safe handling of lasers (see “Laser and LED Safety
Guidelines and Warnings for Switches” on page 155).
Ensure that you have a rubber safety cap available to cover the transceiver.
Figure 32 on page 97 shows how to install a QSFP+ transceiver. The procedure is the
same for all types of transceivers.
To install a transceiver in an EX Series switch:
CAUTION: To prevent electrostatic discharge (ESD) damage to the
transceiver, do not touch the connector pins at the end of the transceiver.
1. Remove the transceiver from its bag.
2. Check to see whether the transceiver is covered with a rubber safety cap. If it is not,
cover the transceiver with a rubber safety cap.
WARNING: Do not leave a fiber-optic transceiver uncovered except when
inserting or removing a cable. The rubber safety cap keeps the port clean
and prevents accidental exposure to laser light.
3. If the port in which you want to install the transceiver is covered with a dust cover,
remove the dust cover and save it in case you need to cover the port later. If you are
hot-swapping a transceiver, wait for at least 10 seconds after removing the transceiver
from the port before installing a new transceiver.
4. Using both hands, carefully place the transceiver in the empty port. The connectors
must face the switch chassis.
CAUTION: Before you slide the transceiver into the port, ensure that the
transceiver is aligned correctly. Misalignment might cause the pins to
bend, making the transceiver unusable.
5. Slide the transceiver in gently until it is fully seated. If you are installing a CFP
transceiver, tighten the captive screws on the transceiver by using your fingers.
6. Remove the rubber safety cap when you are ready to connect the cable to the
transceiver.
WARNING: Do not look directly into a fiber-optic transceiver or into the
ends of fiber-optic cables. Fiber-optic transceivers and fiber-optic cables
connected to transceivers emit laser light that can damage your eyes.
Copyright © 2015, Juniper Networks, Inc.96
Complete Hardware Guide for EX3300 Ethernet Switches

Table of Contents

Other manuals for Juniper EX3300

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Juniper EX3300 and is the answer not in the manual?

Juniper EX3300 Specifications

General IconGeneral
Ethernet LANYes
Authentication methodRADIUS, TACACS+
Connectivity technologyWired
Ethernet interface typeGigabit Ethernet
Number of VLANs4096
Networking standardsIEEE 802.1ab, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3z
Ethernet LAN data rates10, 100, 1000 Mbit/s
Copper ethernet cabling technology1000BASE-T, 100BASE-TX, 10BASE-T
Console port-
ExpressCard slotNo
Fiber ports quantity4
USB 2.0 ports quantity0
Basic switching RJ-45 Ethernet ports quantity48
Throughput130 Mpps
Number of queues8
MAC address table16000 entries
Maximum data transfer rate176 Gbit/s
Supported data transfer rates10, 100, 1000Mbps
Switch typeManaged
Switch layerL2
Security algorithmsSSH-2
Power sourceAC
AC input voltage100 - 240 V
Power consumption (typical)100 W
Form factor1U
Product colorBlack
Flash memory1024 MB
Processor frequency1000 MHz
Compatible operating systemsJunos
Operating altitude0 - 3049 m
Non-operating altitude0 - 4877 m
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)0 - 45 °C
Storage relative humidity (H-H)0 - 95 %
Operating relative humidity (H-H)10 - 85 %
Supported network protocolsIPv6
Weight and Dimensions IconWeight and Dimensions
Depth310 mm
Width437 mm
Height44 mm
Weight4900 g
