Juniper EX3400 Features Guide

CHAPTER 5
DHCPv6 Relay Agent
•
DHCPv6 Relay Agent Overview on page 85
•
Inserting DHCPv6 Interface-ID Option (Option 18) In DHCPv6 Packets on page 86
•
Verifying and Managing DHCPv6 Relay Configuration on page 87
DHCPv6 Relay Agent Overview
The DHCPv6 relay agent enhances the DHCP relay agent by providing support in an IPv6
network. The DHCPv6 relay agent passes messages between the DHCPv6 client and the
DHCPv6 server, similar to the way DHCP relay agent supports an IPv4 network.
When a DHCPv6 client logs in, the DHCPv6 relay agent uses the AAA service framework
to interact with the RADIUS server to provide authentication and accounting. The RADIUS
server, which is configured independently of DHCP, authenticates the client and supplies
the IPv6 prefix and client configuration parameters, such as session timeout and the
maximum number of clients allowed per interface.
NOTE: The PTX Series Packet Transport Routers do not support
authentication for DHCPv6 relay agents.
The DHCPv6 relay agent is compatible with the DHCP local server and the DHCP relay
agent, and can be enabled on the same interface as either the DHCP local server or DHCP
relay agent.
To configure the DHCPv6 relay agent on the router (or switch), you include the dhcpv6
statement at the [edit forwarding-options dhcp-relay] hierarchy level.
You can also include the dhcpv6 statement at the following hierarchy levels:
•
[edit logical-systems logical-system-name forwarding-options dhcp-relay]
•
[edit logical-systems logical-system-name routing-instances routing-instance-name
forwarding-options dhcp-relay]
•
[edit routing-instances routing-instance-name forwarding-options dhcp-relay]
85Copyright © 2017, Juniper Networks, Inc.

Juniper EX3400 Specifications

General

Switch type	Managed
Switch layer	L2/L3
Quality of Service (QoS) support	Yes
Safety	UL-UL60950-1, C-UL CAN/CSA 22.2 No.60950-1, TUV/GS to EN 60950-1, CB-IEC60950-1, EN 60825-1
Form factor	1U
Product color	Black
Electromagnetic compatibility	FCC 47CFR 15 A, EN 55022 A, ICES-003 A, VCCI A, AS/NZS CISPR 22 A, CISPR 22 A, EN 55024, EN 300386, CE
SFP+ module slots quantity	4
QSFP+ module slots quantity	2
Installed SFP+ modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	48
Memory type	DRAM
Noise level	35 dB
Flash memory	2000 MB
Processor frequency	1000 MHz
Virtual stacking (units)	10
Throughput	250 Mpps
Jumbo frames	9216
MAC address table	32000 entries
Number of VLANs	4093
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3z
Virtual LAN features	Port-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Power consumption (max)	120 W
Number of power supply units	1
Operating altitude	0 - 3048 m
Non-operating altitude	3048 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %
DHCP features	DHCP server, DHCP client
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, HTTPS, SNMP, SSH-2
Fiber ethernet cabling technology	1000BASE-X

Weight and Dimensions

Depth	350 mm
Width	437 mm
Height	44 mm
Weight	5740 g
