Juniper EX4600 Hardware Guide

New password: password
Retype new password: password
6. (Oponal) Congure the name of the switch. If the name includes spaces, enclose the name in
quotaon marks (“ ”).
[edit]
root@# set system host-name host-name
7. Congure the default gateway.
[edit]
root@# set routing-options static route default next-hop address
8. Congure the IP address and prex length for the switch management interface.
[edit]
root@# set interfaces em0 unit 0 family inet address address/prefix-length
CAUTION: Although the CLI permits you to congure two management Ethernet
interfaces within the same subnet, only one interface is usable and supported.
NOTE: The management ports, em0 (C0) and em1 (C1) are found on the management panel of
the EX4600 switch.
9. (Oponal) Congure the stac routes to remote prexes with access to the management port.
[edit]
root@# set routing-options static route remote-prefix next-hop destination-ip retain no-readvertise
10. Enable telnet service.
[edit]
root@# set system services telnet
92

Juniper EX4600 Specifications

General

Rack Units	1U
Junos OS	Yes
Product Series	EX Series
DRAM	8 GB
Flash Memory	16 GB
Ports	4 x 40GbE QSFP+ ports
Power Supply	Dual, hot-swappable
MAC Address Table Size	288, 000
Jumbo Frames	9216 bytes
Input Voltage	100-240 V AC
Operating Temperature	0°C to 40°C
Memory	8 GB
Storage	16 GB
