Console Port Connector Pinout Informaon

The console port on a Juniper Networks device is an RS-232 serial interface that uses an RJ-45

connector to connect to a console management device. The default baud rate for the console port is

9600 baud.

Table 28 on page 68 provides the pinout informaon for the RJ-45 console connector.

NOTE: If your laptop or desktop PC does not have a DB-9 plug connector pin and you want to

connect your laptop or desktop PC directly to a device, use a combinaon of the RJ-45-to-DB-9

socket adapter and a USB-to-DB-9 plug adapter. You must provide the USB-to-DB-9 plug

adapter.

Table 28: Console Port Connector Pinout Informaon

Pin Signal Descripon

1 RTS Output Request to send

2 DTR Output Data terminal ready

3 TxD Output Transmit data

4 Signal Ground Signal ground

5 Signal Ground Signal ground

6 RxD Input Receive data

7 CD Input Data carrier detect

8 NC CTS input
