Juniper EX4600 Hardware Guide

Table 24: QSFP+ MPO Fiber-Opc Crossover Cable Pinouts (Connued)
Pin Pin
2 11
3 10
4 9
5 8
6 7
7 6
8 5
9 4
10 3
11 2
12 1
Network Cable Specicaons for EX4600 Switches
EX4600 switches have interfaces that use various types of network cables.
Table 25 on page 61 lists the specicaons for the cables that connect the console (CON) and
management (MGMT) ports to management devices.
60

Juniper EX4600 Specifications

General

Rack Units	1U
Junos OS	Yes
Product Series	EX Series
DRAM	8 GB
Flash Memory	16 GB
Ports	4 x 40GbE QSFP+ ports
Power Supply	Dual, hot-swappable
MAC Address Table Size	288, 000
Jumbo Frames	9216 bytes
Input Voltage	100-240 V AC
Operating Temperature	0°C to 40°C
Memory	8 GB
Storage	16 GB
