Connecng the EX4600 to Power
IN THIS SECTION
Connecng Earth Ground to an EX4600 Switch | 77
Connecng AC Power to an EX4600 Switch | 79
Connecng DC Power to an EX4600 Switch | 81
Connecng
Earth Ground to an EX4600 Switch
To ensure proper operaon and to meet safety and electromagnec interference (EMI) requirements,
you must connect an EX Series switch to earth ground before you connect power to the switch. You
must use the protecve earthing terminal on the switch chassis to connect the switch to earth ground
(see Figure 27 on page 78).
You must install the EX Series switch in a restricted–access locaon and ensure that the chassis is
always properly grounded. EX Series switches have a two–hole protecve grounding terminal provided
on the chassis. Under all circumstances, use this grounding connecon to ground the chassis. For AC-
powered systems, you must also use the grounding wire in the AC power cord along with the two-hole
grounding lug connecon. This tested system meets or exceeds all applicable EMC regulatory
requirements with the two-hole protecve grounding terminal.
Ensure that a licensed electrician has aached an appropriate grounding lug to the grounding cable you
supply. Using a grounding cable with an incorrectly aached lug can damage the switch.
NOTE: Mount your switch in the rack or cabinet before aaching the grounding lug to the
switch. See "Mounng an EX4600 Switch in a Rack or Cabinet" on page 73.
Ensure that you have the following parts and tools available:
Protecve earthing terminal bracket—This bracket aaches to the EX4600 switch chassis through the
le front mounng bracket, providing a protecve earthing terminal for the switch.
Grounding cable for your EX4600 switch—The grounding cable must be 14 AWG (2 mm²), minimum
90° C wire, or as permied by the local code.
77
