Juniper EX4600 Hardware Guide

RJ-45 Management Port Connector Pinout Informaon
Table 29 on page 69 provides the pinout informaon for the RJ-45 connector for the management port
on Juniper Networks devices.
Table 29: RJ-45 Management Port Connector Pinout Informaon
Pin Signal Descripon
1 TRP1+ Transmit/receive data pair 1
2 TRP1- Transmit/receive data pair 1
3 TRP2+ Transmit/receive data pair 2
4 TRP3+ Transmit/receive data pair 3
5 TRP3- Transmit/receive data pair 3
6 TRP2- Transmit/receive data pair 2
7 TRP4+ Transmit/receive data pair 4
8 TRP4- Transmit/receive data pair 4
69

Juniper EX4600 Specifications

General

Rack Units	1U
Junos OS	Yes
Product Series	EX Series
DRAM	8 GB
Flash Memory	16 GB
Ports	4 x 40GbE QSFP+ ports
Power Supply	Dual, hot-swappable
MAC Address Table Size	288, 000
Jumbo Frames	9216 bytes
Input Voltage	100-240 V AC
Operating Temperature	0°C to 40°C
Memory	8 GB
Storage	16 GB
