Juniper EX4600 Hardware Guide

Maintaining the EX4600 Switch Power System
IN THIS SECTION
Removing a Power Supply from an EX4600 Switch | 98
Installing a Power Supply in an EX4600 Switch | 100
Removing a Power Supply from an EX4600 Switch
Before you remove a power supply from an EX4600 switch, ensure that you have taken the necessary
precauons to prevent electrostac discharge (ESD) damage (see Prevenon of Electrostac Discharge
Damage
).
Ensure that you have the following parts and tools available to remove a power supply from an EX4600
switch:
• ESD grounding strap
• Anstac bag or an anstac mat
• Phillips (+) screwdriver, number 2 (DC power supply)
The EX4600 is shipped from the factory with two power supplies. Each power supply is a hot-removable
and hot-insertable eld-replaceable unit (FRU) when the second power supply is installed and running.
You can install replacement power supplies in the two slots next to the fan modules without powering
o the switch or disrupng the switching funcon.
CAUTION: Replace the power supply with a new power supply within 1 minute of
removal to prevent chassis overheang.
To remove a power supply from an EX4600 switch (see Figure 40 on page 99):
1. Place the anstac bag or the anstac mat on a at, stable surface.
2. Aach the ESD grounding strap to your bare wrist, and connect the strap to the ESD point on the
chassis.
98

Juniper EX4600 Specifications

General

Rack Units	1U
Junos OS	Yes
Product Series	EX Series
DRAM	8 GB
Flash Memory	16 GB
Ports	4 x 40GbE QSFP+ ports
Power Supply	Dual, hot-swappable
MAC Address Table Size	288, 000
Jumbo Frames	9216 bytes
Input Voltage	100-240 V AC
Operating Temperature	0°C to 40°C
Memory	8 GB
Storage	16 GB
