Juniper EX4600 Hardware Guide

CPU BUILTIN BUILTIN FPC CPU
PIC 0 BUILTIN BUILTIN 24x10G-4x40G
Xcvr 2 REV 01 740-011614 C09K04908 SFP-LX10
Xcvr 12 REV 01 740-038152 MOC12301520030 SFP+-10G-CU1M
Xcvr 13 REV 01 740-038152 MOC12301520030 SFP+-10G-CU1M
Xcvr 14 REV 01 740-038152 MOC12301520030 SFP+-10G-CU1M
Xcvr 15 REV 01 740-038152 MOC12301520030 SFP+-10G-CU1M
Xcvr 20 REV 01 740-038153 MOC13461530030 SFP+-10G-CU3M
Xcvr 21 REV 01 740-038153 MOC13461530030 SFP+-10G-CU3M
Xcvr 22 REV 01 740-038153 MOC13461530030 SFP+-10G-CU3M
Xcvr 23 REV 01 740-038153 MOC13461530030 SFP+-10G-CU3M
Xcvr 24 REV 01 740-038153 MOC13461530030 QSFP+-40G-CU3M
PIC 1 REV 02 611-049556 RS3113520027 EX4600-EM-8F
PIC 2 REV 02 611-049555 RR3113310086 QFX-EM-4Q
Xcvr 0 REV 01 740-038152 MOC12301520030 QSFP+-40G-CU1M
Power Supply 1 REV 03 740-041741 1GA23381854 JPSU-650W-AC-AFO
Fan Tray 0 QFX5100 Fan Tray 0, Front to Back
Airflow - AFO
Fan Tray 1 QFX5100 Fan Tray 1, Front to Back
Airflow - AFO
Fan Tray 2 QFX5100 Fan Tray 2, Front to Back
Airflow - AFO
Fan Tray 3 QFX5100 Fan Tray 3, Front to Back
Airflow - AFO
Fan Tray 4 QFX5100 Fan Tray 4, Front to Back
Airflow - AFO
{master:0}
root@RIDGE_IEEE>
root@RIDGE_IEEE> show version
fpc0:
NOTE: The EX4600 and QFX5100 use the same fan modules. These modules are represented in
CLI output as QFX5100 fan trays.
130

Juniper EX4600 Specifications

General

Rack Units	1U
Junos OS	Yes
Product Series	EX Series
DRAM	8 GB
Flash Memory	16 GB
Ports	4 x 40GbE QSFP+ ports
Power Supply	Dual, hot-swappable
MAC Address Table Size	288, 000
Jumbo Frames	9216 bytes
Input Voltage	100-240 V AC
Operating Temperature	0°C to 40°C
Memory	8 GB
Storage	16 GB
