Juniper SRX300 Series Reference Guide

The PoE ports for the SRX550 High Memory Services Gateway reside on the individual XPIMs. The SRX550
High Memory Services Gateway supports the 16-Port Gigabit Ethernet XPIM with PoE.
The active Services and Routing Engine manages the overall system PoE power. You can configure the
services gateway to act as power sourcing equipment to supply the power to the GPIMs connected on
the designated PoE ports.
Table 11 on page 27 lists the PoE specifications for the SRX550 High Memory Services Gateway.
Table 11: PoE Specifications for the SRX550 High Memory Services Gateway
SRX550 High Memory Services GatewayPower Management Schemes
•
IEEE 802.3 af
•
IEEE 802.3 at
•
Legacy
Supported standards
PoE is supported on the front panel slots 3,4,6, and 8.Supported slots/ports
The 645 W AC and 645 W DC power supplies support the
following capacities:
•
255 W —PoE on a single power supply, or with redundancy
using the two-power-supply option
•
510 W —PoE using the two-power-supply option operating
as nonredundant
Total PoE power sourcing capacity
31.2 WPer-port power limit
•
Static: Power allocation for each interface can be configured.
•
Class: Power for interfaces is allocated based on the class
of powered device connected.
Power management modes
SRX300 Series and SRX550 High Memory Services Gateway Interfaces
Power and Heat Requirements
Table 12 on page 27 shows the power consumption values of each Physical Interface Module (PIM).
Table 12: PIM Power Consumption Values
Power Consumption (Watts)PIM Model
4.29Serial Mini-PIM
27

Juniper SRX300 Series Specifications

General

Memory	4 GB
CPU	Intel Atom
Storage	8 GB
Operating Temperature	32°F to 104°F (0°C to 40°C)
Humidity	10% to 90% noncondensing
