Juniper SRX300 Series Reference Guide

Table 32: RJ-48 Connector to DB-15 Connector (Crossover) Pinouts (continued)
Signal
DB-15 Pin (Data Numbering
Form)
RJ-48 Pin (on T1/E1
Mini-PIM)
TX/Tip/+ <––>RX/Tip/+35
Shield/Return/Ground43
Shield/Return/Ground26
No connectNo connect7
No connectNo connect8
No connectNo connect9
No connectNo connect10
No connectNo connect11
No connectNo connect12
No connectNo connect13
No connectNo connect14
No connectNo connect15
1-Port T1/E1 Mini-Physical Interface Module (SRX-MP-1T1E1-R) Basic Configuration
IN THIS SECTION
Using the J-Web Interface | 55
Using the CLI | 55
To enable the 1-Port T1/E1 Mini-Physical Interface Module (Mini-PIM) installed on the services gateway,
you must configure the basic settings for the PIM. You can perform the configuration tasks for this using
either the J-Web interface or the CLI.
54

Juniper SRX300 Series Specifications

General

Memory	4 GB
CPU	Intel Atom
Storage	8 GB
Operating Temperature	32°F to 104°F (0°C to 40°C)
Humidity	10% to 90% noncondensing
