Table 15: Juniper Networks Serial Cables (continued)
Connector TypeLengthInterface TypeProduct Number
Female3.04 m (10 ft)RS232 cable (DCE)JX-CBL-RS232-DCE
Male3.04 m (10 ft)RS232 cable (DTE)JX-CBL-RS232-DTE
Female3.04 m (10 ft)RS449 cable (DCE)JX-CBL-RS449-DCE
Male3.04 m (10 ft)RS449 cable (DTE)JX-CBL-RS449-DTE
Female3.04 m (10 ft)V.35 cable (DCE)JX-CBL-V35-DCE
Male3.04 m (10 ft)V.35 cable (DTE)JX-CBL-V35-DTE
Female3.04 m (10 ft)X.21 cable (DCE)JX-CBL-X21-DCE
Male3.04 m (10 ft)X.21 cable (DTE)JX-CBL-X21-DTE
EIA-530A DCE and DTE Cable Pinouts
IN THIS SECTION
EIA-530A DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module | 31
EIA-530A DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module | 33
EIA-530A DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module
Table 16 on page 31 gives the EIA-530A DCE cable pinouts.
Table 16: EIA-530A DCE Cable Pinouts for the 1-Port Serial Mini-PIM
DescriptionLFH-60 PairingDB-25 PinLFH-60 Pin
Shield Ground-115
Transmit Data (A)221
31
