Juniper SRX300 Series Reference Guide

Table 18: RS-232 DCE Cable Pinouts for the 1-Port Serial Mini-PIM
DescriptionLFH-60 PairingDB-25 PinLFH-60 Pin
Frame Ground-115
Transmit Data-21
Receive Data-360
Request to Send-437
Clear to Send-548
Data Set Ready-633
Signal Ground-757
Data Carrier Detect-813
Transmit Clock-1556
Receive Clock-1752
Local Loopback-1845
Data Terminal Ready-209
Terminal Clock-245
---22 to 21
RS-232 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module
Table 19 on page 35 gives the RS-232 DTE cable pinouts.
Table 19: RS-232 DTE Cable Pinouts for the 1-Port Serial Mini-PIM
Description
LFH-60
PairingDB-25 PinLFH-60 Pin
Frame Ground-115
Transmit Data-260
35

Juniper SRX300 Series Specifications

General

Memory	4 GB
CPU	Intel Atom
Storage	8 GB
Operating Temperature	32°F to 104°F (0°C to 40°C)
Humidity	10% to 90% noncondensing
