Juniper SRX300 Series - RS-232 DCE and DTE Cable Pinouts; RS-232 DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module

Table 17: EIA-530A DTE Cable Pinouts for the 1-Port Serial Mini-PIM (continued)
DescriptionLFH-60 PairingDB-25 PinLFH-60 Pin
Receive Data (B)1162
Receive Clock (A)6175
Local Loopback-1841
Request to Send (B)481947
Data Terminal Ready (A)-2033
Signal Ground-234
Terminal Timing (A)512452
---26 to 25
---30 to 29
---18 to 17
RS-232 DCE and DTE Cable Pinouts
IN THIS SECTION
RS-232 DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module | 34
RS-232 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module | 35
RS-232 DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module
Table 18 on page 35 gives the RS-232 DCE cable pinouts.
