Juniper SRX300 Series Reference Guide

1-Port VDSL2 Annex A Mini-Physical Interface Module
(SRX-MP-1VDSL2-R)
IN THIS SECTION
1-Port VDSL2 Annex A Mini-Physical Interface Module (SRX-MP-1VDSL2-R) Overview | 57
1-Port VDSL2 Annex A Mini-Physical Interface Module (SRX-MP-1VDSL2-R) Hardware Specifications | 58
1-Port VDSL2 Annex A Mini-Physical Interface Module (SRX-MP-1VDSL2-R) LEDs | 59
1-Port VDSL2 Annex A Mini-Physical Interface Module (SRX-MP-1VDSL2-R) Supported Profiles | 59
1-Port VDSL2 Annex A (SRX-MP-1VDSL2-R) Mini-Physical Interface Module Cable Specifications | 60
1-Port VDSL2 Annex A Mini-Physical Interface Module (SRX-MP-1VDSL2-R) Basic Configuration | 61
1-Port VDSL2 Annex A Mini-Physical Interface Module (SRX-MP-1VDSL2-R)
Overview
Very-high-bit-rate digital subscriber line (VDSL) technology is part of the xDSL family of modem
technologies, which provide faster data transmission over a single flat untwisted or twisted pair of copper
wires. The 1-Port VDSL2 Annex A Mini-PIM carries the Ethernet backplane. When the Mini-PIM is plugged
into the chassis, the Mini-PIM connects to one of the ports of the baseboard switch. The 1-Port VDSL2
Annex A Mini-PIM on the SRX Series Services Gateway provides ADSL backward compatibility.
The 1-Port VDSL2 Annex A Mini-PIM is compatible with the ITU-T G.993.2 (VDSL2) standard.
Figure 6 on page 57 shows the 1-Port VDSL2 Annex A (SRX-MP-1VDSL2-R) Mini-PIM.
Figure 6: VDSL2 Annex A (SRX-MP-1VDSL2-R) Mini-PIM
57

Juniper SRX300 Series Specifications

General

Memory	4 GB
CPU	Intel Atom
Storage	8 GB
Operating Temperature	32°F to 104°F (0°C to 40°C)
Humidity	10% to 90% noncondensing
