Configuring the LTE Mini-PIM
NOTE: If a services gateway with factory-default settings is powered on with the LTE Mini-PIM
installed in slot 1, the dialer interface is triggered to dial automatically. This functionality is
applicable only if the Mini-PIM is installed in slot 1. If the Mini-PIM is installed in any other slot,
then you will need to manually configure the cl-slot-number/0/0 interface to be associated with
the dialer interface.
To configure the Mini-PIM:
1. Configure the dialer pool:
user@host# set interfaces cl-slot-number/0/0 dialer-options pool number priority number
2. Configure the profile:
user@host# request modem wireless create-profile profile-id profile-id access-point-name l3vpn.corp
authentication-method chap sip-user-id user@myvpn.net sip-password password
3. Activate the SIM:
user@host# set interfaces cl-slot-number/0/0 act-sim sim-slot-number
4. Select the profile and configure the radio access type for the SIM card:
user@host# set interfaces cl-slot-number/0/0 cellular-options sim sim-slot-number profile-id profile-id
user@host# set interfaces cl-slot-number/0/0 cellular-options sim sim-slot-number radio-access
automatic
NOTE: If a SIM card is installed in the second slot, then select the profile and configure
the radio access type for the secondary SIM card as well.
5. Configure the dialer interface:
•
Always-on mode:
user@host# set interfaces dl0 unit 0 family inet negotiate-address
user@host# set interfaces dl0 unit 0 family inet6 negotiate-address
user@host# set interfaces dl0 unit 0 dialer-options pool dialer-pool-number
user@host# set interfaces dl0 unit 0 dialer-options dial-string dial-number
85
